X-ray Diffraction Facility

Explore the ANU Research School of Chemistry's X-ray Facility: a hub for advanced research supporting a broad range of disciplines with several X-ray diffractometers, support infrastructure and analysis tools/expertise for the characterisation of crystalline solids. Perfect for scientific exploration and discovery. Available to ANU researchers and external clients.

contact_support Contact
Dr Michael Gardiner
michael.gardiner@anu.edu.au

Content navigation

About

XRD Banner

The Research School of Chemistry houses five modern single crystal and powder X-ray diffractometers that cater for vastly diverse fields of research. The X-Ray Diffraction Facility is housed in a large purpose-built laboratory and supports chemical and macromolecular crystallography, and material identification and characterisation offering a broad range of capabilities for studying many sample types in a range of sample environments. For further detail see the equipment sections below. Common sample types include, but are not limited to, pure and heterogeneous powders, single crystals of small molecules and macromolecules, solid state materials, polymers, thin films, textured surfaces, fibres, polished prepared mineral specimens, as well as bulk mineral and artefact samples up to 10 kg.

Access costs and user induction processes for ANU users are detailed on the RSC intranet site. External users please make contact to discuss requirements and obtain a quotation.

Reasons to work with us

  • World class single crystal and powder diffractometers maintained by a full-time experienced crystallographer.
  • Expertise in handling difficult chemical crystallography structures (modulated structures, twinning, extensive disorder).
  • Expertise and unique accessories for handling/transfer and mounting of sensitive samples (air/moisture/thermally sensitive samples, rapid solvent loss using purpose designed microscope stage cold mounting devices at temperatures as low as -110 °C).
  • Wide capabilities of powder diffraction measurements, from routine bulk powder Bragg-Brentano measurements to high resolution capillary data collection for structure determination, through thin film, textured samples, reflectometry and some small angle scattering measurements, and also bulk mineral and artefact samples up to 10 kg.
  • The Facility functions as a portal to access various national and international X-ray and neutron-based research facilities and strengthen beamtime proposals success rates by providing initial powder and single crystal laboratory X-ray source measurements that are often mandatory.
  • Access to the MX1/2 crystallography beamlines at the Australian Synchrotron is available with limited lag time via an established Collaborative Access Program project.
  • Competitive instrument and analysis costs with flexibility of DIY data collection or fee-for-service full sample analysis and reporting to suit your preferences and experience.

Equipment

Advanced Single Crystal Mounting

Exceptional humidity and temperature control at the microscope is available for sensitive samples with MiTeGen WaterShed and bespoke inhouse developed low temperature devices, backed up with standard cryo-storage and transportation equipment compatible with most of the world's synchrotron beamlines

Read more
National Facilities Conduit

Our instruments also serve as the necessary conduit to access various national facilities through initial laboratory X-ray source measurements, such as ANSTO's Australian Synchrotron and Australian Centre for Neutron Scattering, and the NCRIS network.

Read more
Optical Microscopes

High specification Leica and two Olympus stereo zoom microscopes for routine and demanding synchrotron sample mounting and image recording

Read more
Powder Diffractometers

Two Malvern Panalytical Empyrean multipurpose high resolution instrument platforms with wide configuration capabilities using a large suite of optics and sample environment accessories, as well as a Bruker D2 Phaser benchtop instrument for walkup routine measurements

Read more
Single Crystal Diffractometers

Agilent SuperNova (dual microfocus source upgraded with HyPix-6000HE detector, Cu and Mo radiation) and xCalibur (Mo radiation) instruments fitted with Oxford Cryosystems sample coolers

Read more
Software and Databases

The RSC holds subscriptions to the leading single crystal (Cambridge Structural Database) and powder (Inorganic Crystal Structure Database) diffraction databases with intuitive, sophisticated searching GUI tools. For advanced powder diffraction analysis, we hold multiple licenses for the Panalytical HighScorePlus package. In addition, we have installed versions and expertise in a wide range of discipline-recognised crystallographic analysis tools.

Read more
